巨腾网站建设,中国交通建设集团有限公司地址,直播间网站建设,搜索引擎平台有哪些Docker之jenkins部署harbor在harbor中完成部署 1、harbor作用 Harbor允许用户用命令行工具对容器镜像及其他Artifact进行推送和拉取#xff0c;并提供了图形管理界面帮助用户查阅和删除这些Artifact。在Harbor 2.0版本中#xff0c;除容器镜像外#xff0c;Harbor对符合OCI…Docker之jenkins部署harbor在harbor中完成部署 1、harbor作用 Harbor允许用户用命令行工具对容器镜像及其他Artifact进行推送和拉取并提供了图形管理界面帮助用户查阅和删除这些Artifact。在Harbor 2.0版本中除容器镜像外Harbor对符合OCI规范的Helm Chart、CNAB、OPA Bundle等都提供了更多的支持。另外Harbor为管理员提供了丰富的管理功能特别是作为开源软件随着版本的迭代很多社区用户的反馈和贡献被吸收进来以便更好地适应。 2、harbor下载 https://github.com/goharbor/harbor/releases/tag/v2.8.3 3、安装 将里面的harbor.yml.temp 复制一份变成harbor.yml文件然后修改下面几个

Configuration file of Harbor# The IP address or hostname to access admin UI and registry service.

DO NOT use localhost or 127.0.0.1, because Harbor needs to be accessed by external clients.

hostname: harbor.ycz.com # 这里改之后在etc/host中新增# http related config http:# port for http, default is 80. If https enabled, this port will redirect to https portport: 8000 # 这里改# https related config #https: # 注释# https port for harbor, default is 443# port: 443 # 注释# The path of cert and key files for nginx# certificate: /your/certificate/path# private_key: /your/private/key/path# # Uncomment following will enable tls communication between all harbor 启动 sudo ./install.sh [Step 0]: checking if docker is installed …Note: docker version: 24.0.2[Step 1]: checking docker-compose is installed …Note: Docker Compose version v2.19.1[Step 2]: loading Harbor images … Loaded image: goharbor/registry-photon:v2.8.3 Loaded image: goharbor/notary-server-photon:v2.8.3 Loaded image: goharbor/notary-signer-photon:v2.8.3 Loaded image: goharbor/harbor-log:v2.8.3 Loaded image: goharbor/redis-photon:v2.8.3 Loaded image: goharbor/harbor-jobservice:v2.8.3 Loaded image: goharbor/prepare:v2.8.3 Loaded image: goharbor/harbor-core:v2.8.3 Loaded image: goharbor/harbor-registryctl:v2.8.3 Loaded image: goharbor/nginx-photon:v2.8.3 Loaded image: goharbor/trivy-adapter-photon:v2.8.3 Loaded image: goharbor/harbor-portal:v2.8.3 Loaded image: goharbor/harbor-db:v2.8.3 Loaded image: goharbor/harbor-exporter:v2.8.3[Step 3]: preparing environment …[Step 4]: preparing harbor configs … prepare base dir is set to /Users/mac/docker/harbor WARNING:root:WARNING: HTTP protocol is insecure. Harbor will deprecate http protocol in the future. Please make sure to upgrade to https Clearing the configuration file: /config/portal/nginx.conf Clearing the configuration file: /config/core/app.conf Clearing the configuration file: /config/core/env Clearing the configuration file: /config/jobservice/env Clearing the configuration file: /config/jobservice/config.yml Clearing the configuration file: /config/nginx/nginx.conf Clearing the configuration file: /config/registry/config.yml Clearing the configuration file: /config/registry/passwd Clearing the configuration file: /config/db/env Clearing the configuration file: /config/log/logrotate.conf Clearing the configuration file: /config/log/rsyslog_docker.conf Clearing the configuration file: /config/registryctl/env Clearing the configuration file: /config/registryctl/config.yml Generated configuration file: /config/portal/nginx.conf Generated configuration file: /config/log/logrotate.conf Generated configuration file: /config/log/rsyslog_docker.conf Generated configuration file: /config/nginx/nginx.conf Generated configuration file: /config/core/env Generated configuration file: /config/core/app.conf Generated configuration file: /config/registry/config.yml Generated configuration file: /config/registryctl/env Generated configuration file: /config/registryctl/config.yml Generated configuration file: /config/db/env Generated configuration file: /config/jobservice/env Generated configuration file: /config/jobservice/config.yml loaded secret from file: /data/secret/keys/secretkey Generated configuration file: /compose_location/docker-compose.yml Clean up the input dirNote: stopping existing Harbor instance …[Step 5]: starting Harbor … [] Running 10/10✔ Network harbor_harbor Created 0.1s ✔ Container harbor-log Started 0.7s ✔ Container registryctl Started 1.4s ✔ Container harbor-portal Started 1.5s ✔ Container harbor-db Started 1.5s ✔ Container redis Started 1.8s ✔ Container registry Started 1.8s ✔ Container harbor-core Started 2.0s ✔ Container nginx Started 2.5s ✔ Container harbor-jobservice Started 2.5s ✔ —-Harbor has been installed and started successfully.—-4、访问 默认密码时 admin Harbor12345 5、新增一个仓库随便取名字 6、docker随便弄一个镜像试试能不能上传到仓库上 将mytest的重命名了命名方式为 harbor地址/项目名/镜像名:版本 macdeMacBook-Pro:harbor mac\( docker tag 84fd17f590f0 harbor.ycz.com:8000/repo/mytest:latest macdeMacBook-Pro:harbor mac\) docker images REPOSITORY TAG IMAGE ID CREATED SIZE mytest latest 84fd17f590f0 32 minutes ago 558MB harbor.ycz.com:8000/repo/mytest latest 84fd17f590f0 32 minutes ago 558MBpush上去发现没有权限 macdeMacBook-Pro:~ mac\( docker push harbor.ycz.com:8000/repo/mytest:latest The push refers to repository [harbor.ycz.com:8000/repo/mytest] 0eeca62d60e3: Preparing 508262fdcf74: Preparing 99417f399c4c: Preparing 6b5aaff44254: Preparing 53a0b163e995: Preparing b626401ef603: Waiting 9b55156abf26: Waiting 293d5db30c9f: Waiting 03127cdb479b: Waiting 9c742cd6c7a5: Waiting unauthorized: unauthorized to access repository: repo/mytest, action: push: unauthorized to access repository: repo/mytest, action: push登陆之后再push macdeMacBook-Pro:~ mac\) docker login -u admin -p Harbor12345 harbor.ycz.com:8000 WARNING! Using –password via the CLI is insecure. Use –password-stdin. Login Succeeded macdeMacBook-Pro:~ mac\( docker push harbor.ycz.com:8000/repo/mytest:latest The push refers to repository [harbor.ycz.com:8000/repo/mytest] 0eeca62d60e3: Pushed 508262fdcf74: Pushed 99417f399c4c: Pushed 6b5aaff44254: Pushed 53a0b163e995: Pushed b626401ef603: Pushed 9b55156abf26: Pushed 293d5db30c9f: Pushed 03127cdb479b: Pushed 9c742cd6c7a5: Pushed latest: digest: sha256:68fa7d0fef4a2c8286cf195a6a7566f58f86349c5e04829f84083feae31eee99 size: 2421 成功 将刚刚push之前的harbor.ycz.com:8000/repo/mytest:latest删了之后再从repo中拉取试试看 macdeMacBook-Pro:~ mac\) docker pull harbor.ycz.com:8000/repo/mytest:latest latest: Pulling from repo/mytest Digest: sha256:68fa7d0fef4a2c8286cf195a6a7566f58f86349c5e04829f84083feae31eee99 Status: Downloaded newer image for harbor.ycz.com:8000/repo/mytest:latest harbor.ycz.com:8000/repo/mytest:latestWhats Next?View summary of image vulnerabilities and recommendations → docker scout quickview harbor.ycz.com:8000/repo/mytest:latest7、将原来的jenkins项目构建docker中改成这样 docker build -t mytest /var/jenkins_home/workspace/test docker login -u admin -p Harbor12345 harbor.ycz.com:8000 docker tag mytest:latest harbor.ycz.com:8000/repo/mytest:latest docker push harbor.ycz.com:8000/repo/mytest:latest成功构建 成功push到harbor 8、需要在harbor服务器中编写docker构建的代码 告知服务器拉取哪个镜像判断当前的服务器是否在进行需要删除如果目标服务器已经存在当前的镜像需要删除目标服务器拉取harbor上的镜像将拉取下来的镜像运行成容器 vi deploy.sh harbor_addr\(1 harbor_repo\)2 project\(3 version\)4 container_port\(5 host_port\)6imageName\(harbor_addr/\)harbor_repo/\(project:\)versionecho \(imageNamecontainerIddocker ps -a | grep \){project} | awk {print \(1}echo \)containerIdif [ \(containerId ! ] ; thendocker stop \)containerIddocker rm \(containerId fitagdocker images | grep \){project} | awk {print \(2}echo \)tagif [[ \(tag ~ \)version ]] ; thendocker rmi \(imageName fidocker login -u admin -p Harbor12345 \)harbor_addrdocker pull \(imageNamedocker run -d -p \)host_port:\(container_port --name \)project $imageNameecho SUCCESS9、jenkins构建 到这里修改目标的host 再修改jenkins的构建 ![在这里插入图片描述](https://img-blog.csdnimg.cn/ccedeb6db6e646a5bceb580d7f742706.png 成功
